Sapphire substrate 10*10mm high-precision laser scribing cutting, special shapes and sizes can be customized

Availability:
Quantity:


Sapphire pieces (2)Sapphire pieces (3)Sapphire pieces (1)Sapphire window (7)Sapphire sapphire laser rod (window, lens, prism, tube, special shape, light guide block) (1)Sapphire sapphire laser rod (window, lens, prism, tube, special shape, light guide block) (2)


The sapphire crystal light guide block for laser beauty equipment (IPL) is a sapphire crystal with high transparency and purity. The light guide block used for laser beauty equipment is a cuboid optical glass with all six sides of optical glass. Polishing, coating a cut-off filter film on one of the end surfaces, the transmitted light is totally reflected around the light guide block and finally emitted from the other end surface, and then irradiated to the skin surface for laser beauty.


Light guide block detailed description


Material: Sapphire crystal


Peak transmittance: >90%


Clear aperture: >95%


Dimension tolerance: +/-0.1mm


Length tolerance: +/-0.1mm


Light guide block size: customized production


Chamfer of light guide block: around the incident surface <0.1X45°, the rest <0.3~0.5X45°


Surface finish: National standard three; US military standard: 60-40/40-20


The optical wavelength bands of the sapphire crystal light guide block mainly coated are:


430nm, 480nm: acne/acne removal|530nm: freckle removal/wrinkle removal|560nm: whitening and rejuvenation|580nm: red blood streak removal|640nm/670nm/690nm: hair removal|removal of hair | custom-made filters


Advantages of light guide block for beauty equipment:

a. High-precision technology processing and good surface quality and durability.

b. The crystal material has excellent optical, thermodynamic and mechanical properties.

c. The coating machine process is produced, which can withstand laser pulses for a long time, ensuring the safety of cosmetic equipment surgery.

d. Coating machine process production, dense film, high damage threshold, longer service life.
